K8000 Series
K8000 Series
K6000 Series
Features
ㆍ Cast iron body
ㆍ One valve regulates closing and latching speed.
ㆍ Can be used for right and left swing doors of up to 120 Kg.
ㆍ Hold open at 90 degree , 115degree.
Optional Features
ㆍ Both-side free (Non-stop type)
ㆍ Both-side hold (Hold-open type)
ㆍ One-side hold (Hold-open type)Opening Angle
ㆍ HOLD OPEN ANGLE 90°, 115°
Selection Chart
Both-side hold Both-side free One-side hold One-side free Door size (mm)
Weight(Kg)K6200 K6200N K6200S K6200NS 900x2100
40-65K6300 K6300N K6300S K6300NS 950x2100
60-85K6400 K6400N K6400S K6400NS 1050x2400
80-120
